TMPRO Software module 30
– Renault UCH Sagem
This software can be used in 2 ways:
1.If you don`t know 12-digit PIN code:Memory device is serial eeprom 93c66 SMD8 package.
Expected file size is 512 bytes.Module shows PIN code.
Use PCF7936 or Silca T14 – JMA TP12 or CN3 transponder.
if you use PCF7936 written transponder have to be matched with car using diagnostic device,if you use CN3 no need.
2.If you know 12-digit PIN code:Start software and manually select module. Insert PCF7936 or Silca T14 – JMA TP12 transponder.Press PROG button. Software opens box, where you must enter 12-digit PIN code.Verify it and press OK. Match prepared transponder with car using diagnostic device and PIN code.
Vehicles equipped with this unit:
Renault: Clio(2001-2006)
