Main processor:

• Type: iMX6 1GHz
• DDR3L SDRAM: 512 MByte
• Mass Storage: eMMC 8 GByte

Coprocessor:

• Type: STM32H735IGK6 550MHz
• RAM: 2 MByte SRAM, 32 MByte SDRAM
• Flash: 2 MByte

Power connector:

Power: 2.1 DC jack

Diet:

12 – 24 V (DC voltage)
(from vehicle battery via OBD connector or specific wiring)

Absorption:

• 1 A @12 V
• 0.5 A @24 V

USB Connectors:

• USB: USB 2.0 host type A max 1A out
• USB DEVICE: USB 2.0 device type B (priority connector)

Bluetooth communication:

BDR/EDR/LE1M

WiFi communication:

WiFi IEEE 802.11 b/g/n20 (2412 ~ 2462 MHz)

Operating band:

2400 ~ 2483.5 MHz

Maximum transmitted radio frequency power:

10 dBm (2400 ÷ 2483.5 MHz)

Diagnostic connectors:

• DIAGNOSIS: DSUB-26HD (ISO 22900-1)

Electronic switch:

2-way, 13 independent positions

ECU reprogramming connector:

PV (SAE J2534-1)

Supported protocols:

• Blink codes
• K, L (with 60 mA current protection), ISO9141-2, ISO14230
• CAN ISO11898-2 High Speed
• CAN_FD 11898-2:2016 4 channels
• CAN ISO 11898-3 LOW Speed
• CAN SAE J2411 Single Wire
• SAE J1850 PWM
• SAE J1850 VPW
• SAE J2534-1
• SAE J1708
• Ethernet DoIP ISO13400-3

User Interface:

64×128 dot OLED display

Operating temperature:

0 ÷ 50 °C

Storage temperature:

– 20 ÷ 60 °C

Operating and operating humidity:

10 ÷ 80 % non-condensing

Weight:

600 g

IP protection rating:

IP53 (With protective caps tightly closed)

Directives:

• RED 2014/53/EU
• RoHS 2011/65/EU and Delegated Directive 2015/863/EU

Electromagnetic compatibility:

• ETSI EN 301 489-1
• ETSI EN 301 489-17

Radio systems:

ETSI EN 300 328

Electrical safety:

• EN 62368-1
• EN 62311
