DAS4/FBS4 Personalization Expert MN034

The MN034 FBS4 Personalization Expert license allows personalization of second-hand or brand-new FBS4 modules (set to virgin state) with or without available FBS4 data via OBDII and internal CAN-Bus connection. This is a major tool for working with modules from the FBS4 generation Mercedes-Benz vehicles.

Get the job done without the data from the original module!
Fast and user-friendly exchange of modules!
No dealer account needed!

Functionalities:

• Personalization of virgin second-hand modules by OBDII and internal CAN-Bus connection with or without previously saved FBS4 data from the original module
• Personalization of brand-new and unused modules by OBDII and internal CAN-Bus connection WITHOUT the need to set them to virgin state!
• MRD1/MRG1 on bench via ABRITES Distribution Box Set (ZN151) and MD1/MG1 ECU connection cable (CB030)
• MED41 (MED17.7.7) on bench via ABRITES Distribution Box Set (ZN151)
• DSM modules on bench via ABPROG and ZN086
• Inverter Control Module (INV20EM01) via OBD or bench connection
• Delphi CRD3xx via OBD

Disclaimer 1: FBS4 data can be read from modules and saved to file using MN032 license
Disclaimer 2: Modules can be set to virgin state using MN032 or MN039 license

NEW FUNCTIONALITY UPDATE: Personalization of virgin (brand-new or second-hand) modules when NO PREVIOUSLY SAVED PERSONALIZATION DATA FROM THE ORIGINAL MODULE IS AVAILABLE!

• Delphi CRD3NFZ and CRD3S2NFZ ECUs personalization via OBDII without previously saved FBS4 data from the original ECU
